Class 7 | Science
Chapter 8 | Measurement of Time and Motion
Aligned with CBSE | NCERT | School & Olympiad Standards
Focus on What Matters Most
The67Sprint
⏳ Measuring Time — Then & Now
- Early humans tracked time using natural periodic events — sunrise, moon phases — and devices like sundials, water clocks, hourglasses, and candle clocks
- Modern clocks rely on periodic motion: quartz crystal vibrations or atomic vibrations for extreme precision
⚖️ The Simple Pendulum
- A small heavy mass (bob) suspended from a rigid support by a string
- Oscillation: one complete back-and-forth movement — mean position to both extremes and back
- Time Period: the time taken to complete exactly one oscillation
- The time period depends entirely on the length of the string — it does not change even with a heavier or lighter bob
🏃 Speed & Motion
- Speed = total distance covered ÷ total time taken — how fast or slow an object moves
- Uniform Motion: equal distances in equal time intervals (car on cruise control on an empty highway)
- Non-Uniform Motion: unequal distances in equal time intervals — speed keeps changing (bus in city traffic)
Speed = D/T 🏎️
m/s 📏
Memory Cheat Code
The67Sprint
A straight, upward-sloping line on a distance-time graph means uniform motion; a curved line means non-uniform motion; a flat line parallel to the time (X) axis means the object is stationary.
Quick Recall — Sprint Facts
Core Formulas
Speed = Distance/Time | Distance = Speed × Time | Time = Distance/Speed
Speed Conversion
1 km/h = 5/18 m/s | 1 m/s = 18/5 km/h
1656
Christiaan Huygens invented and patented the pendulum clock, inspired by Galileo
Ghatika-yantra
Ancient Indian sinking-bowl water clock — 1 ghati = 24 minutes
Samrat Yantra
World's largest sundial, Jaipur — shadow moves 1 mm every second
Average Speed
Total Distance ÷ Total Time — used specifically for non-uniform motion
The67Sprint
🔑 Key Terms
Mean Position
The central resting point where the pendulum bob hangs vertically due to gravity
Speedometer
Dashboard instrument showing current instantaneous speed in km/h
Odometer
Instrument measuring the total cumulative distance travelled
Average Speed
Total distance ÷ total time — used when speed changes during a journey (non-uniform motion)
SI Unit
Standard unit of measurement — second (s) for time, metre per second (m/s) for speed
Gnomon
The shadow-casting stylus on a sundial that marks the time of day
The67Sprint
The67Sprint
🏆 Olympiad & Challenger Edge
The Pendulum Formula
T = 2π√(L/g) — time period is directly proportional to the square root of length (L) and inversely proportional to local gravity (g). This gravity dependence is Olympiad-level, not core syllabus.
Small-Angle Rule
The time period stays constant regardless of swing width only if the starting angle is small — specifically less than 15°.
Weaker Gravity, Slower Clock
Taken to the Moon or a lighter-gravity planet, the same pendulum swings slower — its time period increases because g is smaller.
Heat & Pendulum Clocks
A brass pendulum string expands in summer heat, increasing L — since T ∝ √L, the clock's time period increases and it runs slow.
❌ "10 secs", "5 hrs"
Wrong. SI unit symbols are always singular — write "10 s" and "5 h", never with a plural "s".
❌ "5 m/s."
Never place a full stop after a unit symbol unless it's the very end of a sentence.
❌ "Distance covered" only
Incomplete. Speed must be defined as distance covered per unit of time, or marks are lost.
🛵 Food Delivery Tracker
A delivery rider's GPS shows speed changing constantly — fast on empty roads, slow in traffic. That's why apps calculate average speed for arrival time, not a single fixed speed.
🛝 Playground Swing Chains
Shortening a swing's chains makes it complete each back-and-forth cycle faster — a real-life demonstration of the pendulum's length-time period link.
🏃 Sports Timing
Race winners are decided by stopwatches accurate to a centisecond (1/100th of a second) or millisecond.
🚨 Heavier bob = faster swing?
No — the time period depends only on string length, never on the mass of the bob.
🚨 "Straight line = uniform motion"
Only true on a distance-time graph, and only if the line is sloped — a horizontal straight line means stationary, not uniform motion.
🚨 Skipping the formula step
Writing only the final numerical answer — without the formula and substituted values — costs partial marks in numericals.
🔗 Logic Chain
Step 1
Observe the distance covered and time taken by a moving object
Step 2
Apply the formula: Speed = Distance ÷ Time
Step 3
Compare distances covered across equal time intervals
Step 4
Constant distance = uniform motion (straight line); varying distance = non-uniform motion (curved line)
Mentor Byte
Before you divide distance by time, make sure they speak the same language — convert kilometres to metres or minutes to hours first. And when you draw a distance-time graph, scale your axes and label them clearly: examiners look for units on both axes before anything else.
