The67Sprint — LearningMap: Symmetry

Symmetry vs. Asymmetry

A figure is symmetrical if its parts repeat in a balanced, proportionate pattern. If it lacks this, it's asymmetrical (like a cloud).
Line of Symmetry: a fold line that splits a figure into two mirror halves that completely overlap when folded.

Polygons & Curved Shapes

A regular polygon has the same number of lines of symmetry as its sides: Triangle (3), Square (4), Pentagon (5), Hexagon (6), Circle (Infinite).
Curved boundaries aren't always "infinite" — a shape can be drawn with a curved edge and still have exactly 1, 2, or 4 fixed lines of symmetry.

Triangle: 3 Square: 4 Hexagon: 6

Rotational Symmetry & Angles

Centre of Rotation: the fixed point a figure turns around.
Angles of Symmetry: list ALL angles where the figure matches itself — not just the smallest one. A square matches at 90°, 180°, 270°, and 360°.
If 360° is the only angle of symmetry, the figure has no rotational symmetry.

The Punching Game

Fold paper, punch a hole, then unfold — the hole reflects across every fold line made.
Folding twice (vertical + horizontal) before one punch produces 4 holes, reflected into all four quadrants.

National Symbols (Core Syllabus)

The New Parliament Building is a direct textbook example — check it for reflection and rotational symmetry.
The Ashoka Chakra has 24 spokes → 24 lines of symmetry, angles of symmetry every 15° (360° ÷ 24).

Quick Recall — Sprint Facts

Square4 lines, angles at 90°,180°,270°,360°

Hexagon6 lines, angles every 60°

RectangleOnly 2 lines — never the diagonals

Vertical LettersA H I M O T U V W X Y

🔑 Key Terms

Axis of Symmetry

The imaginary fold line creating identical mirror halves.

Centre of Rotation

The fixed central point an object is turned around.

Angles of Symmetry

All the angles at which a rotated figure matches its original outline.

Lateral Inversion

Left-right flip produced by a mirror image.

🏆 Olympiad & Challenger Edge

Mirror vs. Water Image

A mirror image is a vertical reflection causing lateral (left-right) inversion. A water image is a horizontal reflection causing upside-down (top-bottom) inversion — left/right stay the same.

Order 1 Trick

If a shape only matches itself after a full 360° turn, it has NO true rotational symmetry — 360° being the only angle of symmetry proves it.

Grid Symmetrization

Find the minimum extra squares to shade in a grid so a given line becomes a true axis of symmetry for the whole figure.

Mandala Angles

A 24-petal mandala repeats every 360° ÷ 24 = 15° — the same logic used for the Ashoka Chakra.

✅ Counting Lines in Regular Polygons

Lines of symmetry = number of sides, for any regular polygon. Practice with pentagon and hexagon, not just square and triangle.

✅ Listing ALL Angles of Symmetry

Don't stop at the smallest angle — write every angle where the figure overlaps itself, e.g. square: 90°, 180°, 270°, 360°.

✅ Alphabet Symmetry Recall

Know all three lists cold: vertical-only, horizontal-only, and both — H, I, O, X have both.

✅ Punching Game Practice

Practice predicting hole positions for single-fold and double-fold punches before the exam — this is a guaranteed question type.

🪁 Kolam & Rangoli

Red petal motifs in Kolam and Rangoli return onto themselves when the pattern is rotated by 90° — living rotational symmetry.

🌀 The Pinwheel

A pinwheel's central hexagon and spinning blades show rotational symmetry in action every time it turns in the wind.

🕌 The Taj Mahal

A vertical line down the centre splits the monument into two perfect mirror halves — reflection symmetry at monumental scale.

❄️ Snowflakes

Every snowflake grows with 6-fold radial (rotational) symmetry, locking into the same shape six times per turn.

🚨 Rectangle Diagonal Trap

Folding a rectangle along its diagonal does NOT make the corners overlap. A rectangle has only 2 lines of symmetry — never the diagonals.

🚨 Order 1 ≠ Symmetrical

"Order 1" means the shape only matches after a full 360° — that means it has NO rotational symmetry, not that it does.

🚨 Semi-Circle Isn't Infinite

A full circle has infinite lines of symmetry, but a semi-circle has exactly ONE — the perpendicular bisector of its flat edge.

🚨 Water Image Direction

Water images flip top-to-bottom, NOT left-to-right. A clock reading 3:00 in water reflection is actually 3:30 on the real clock.

Logic Chain — How a Fold Becomes a Symmetry Rule

Step 1

A fold line divides a figure into two halves — this fold connects directly to whether the halves overlap exactly.

Step 2

If the halves overlap completely, that fold line becomes a true Line of Symmetry, which leads to counting how many such lines exist.

Step 3

Counting all valid lines connects to spinning the same figure around its centre to check for Rotational Symmetry too.

Step 4

Every angle where the spin matches the original leads to the full list of Angles of Symmetry for that figure.

🦉

Mentor Byte

Symmetry isn't memorised, it's felt. Cut a shape, pin it at its centre, and physically turn it — let your hand feel each angle lock into place. When you fold and spin with your own hands, the angles of symmetry write themselves into memory far better than any list ever could.

For Parents

Hand your child a square piece of paper and ask them to find every fold and every turn that makes it match itself again — no worksheet needed.
